24V AC 113-030-0144 113-030-0135 Air Compressor Solenoid Valve Coil

Brand Name : BRANDO

Model Number : BB14542505

Certification : None

Place of Origin : Ningbo, China

MOQ : 1000

Price : Negotiation

Payment Terms : T/T, PayPal, Western Union

Supply Ability : 500000 set per month

Delivery Time : Negotiation

Packaging Details : Inner Box, Carton, Pallet

Type : 0545 110-030 NASS Type

Material : Thermoset resin, Copper

Product name : 0545 110-030 NASS Type Solenoid Valve Coil System 13

Voltage : AC220V AC110V/ DC12V DC24V (±10%)

Hole size : 14.6 mm

Ambient temperature : - 20 °C ~ + 50 °C

Application : Water solenoid valve and electronic drain valve

Insulation class : F, H

Connection type : DIN43650A

Degree of protection with connector : IP 65 (IP 67 on request)

Contact Now

24V AC 113-030-0144 113-030-0135 Air Compressor Solenoid Valve Coil

Main dimension of Nass Type 0545 Electronic Drain Solenoid Coils:

24V AC 113-030-0144 113-030-0135 Air Compressor Solenoid Valve Coil

Technical parameter of 0545 110-030 NASS Type Solenoid Valve Coil:

Code No Voltages Frequency(Hz)
Power (W)
 Power (VA)
113-030-0123 24vDC 4,1
113-030-0144 24VAC 50 8,8
113-030-0144 24VAC 60 7,6
113-030-0128 220VAC 50 9,0
113-030-0128 240VAC 60 9,2
113-030-0142 230VAC 50 8,8
113-030-0142 230VAC 60 7,6
113-030-0121 220VAC 50 14,0
113-030-0124 24VDC - 7,9
113-030-0135 24VAC 50 14,0
113-030-0135 24VAC 60 12,0
113-030-0279 110 VAC 50 13,9
113-030-0279 110VAC 60 12,2
113-030-0125 24VDC - 11,9
113-030-0129 24VAC 50 21,0
113-030-0129 24VAC 60 18,0
113-030-0126 110VAC 50 21,5
113-030-0141 230 VAC 50 22,0
113-030-0141 230VAC 60 19,0
113-030-0120 12VDC - 17,5
113-030-0127 24VAC 50 25,0
113-030-0132 24VDC - 18,5
113-030-0120 36VAC 50 25,0
113-030-0137 110VAC 50 27,5
113-030-0140 110VAC 60 26,5
113-030-0137 120VAC 60 28,0
113-030-0133 220VAC 50 25,5
113-030-0122 220VAC 50 22,0
113-030-0138 230VAC 50 25,5
113-030-0133 240VAC 60 25,0
113-030-0138 240VAC 60 27,0

Phyical map of 113-030-0028 nass type electromagnetic coil:

24V AC 113-030-0144 113-030-0135 Air Compressor Solenoid Valve Coil

Applicatoin of nass type 113-030-0035 electric magnetic coil:

24V AC 113-030-0144 113-030-0135 Air Compressor Solenoid Valve Coil

More details about 0545 110-030 series Solenoid Coil can be found below the Youtube Video:

Product Features:
1. Using high quality wire which has UL approved; 2. Using high quality permeablity magnetic material which contain low carbon;
3. Using high quality housing material like PA66, PBT, PPS, BMC and so on.
4. Insulation class can be B, F, H, N, C;
5. Protection class can be IP65, IP67 & IP69K;
6. We also offer special coils like ex-proof coils, water proof coils and so on.
7. If you have special requirement, pls feel free to contact us.

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing

​

Welcome to your any question and inquiry!
